Get A Sharper View From A Connected Helm

With its sleek design powerful processing and upgraded IPS display this advanced 12″ chartplotter integrates seamlessly into a Garmin marine system. The compact 18″ dome radar combines ease of use with powerful scanning features that work to maximise confidence and situational awareness on the water.

See The World Below

Ultra High-Definition Scanning Sonar - Get built-in Ultra High-Definition SideVü and ClearVü scanning sonars with vivid high-contrast colour palettes to help distinguish fish from structure. GPSMAP X3 series also supports 1 kW CHIRP traditional sonar capabilities.

Panoptix & Livescope Sonar Support - Pair with Panoptix or LiveScope easy-to-interpret live sonar (transducer required sold separately) to see all around the boat in real time.

Made for the Helm

Faster Sharper Smarter - With its added processing power and new slimline design featuring edge-to-edge glass and a smaller unit footprint it’s easy to retrofit this plotter in a wider range of dash configurations.

Improved Display Optics - New higher-resolution IPS displays for 9″ and 12″ plotters offer improved sunlight readability and visibility from any angle with 50% more pixels than previous-generation 9″ GPSMAP devices.

Charts and Maps - Bring a fresh new look and feel to the chartplotter with optional Garmin Navionics+ or premium Garmin Navionics Vision+ cartography featuring integrated coastal/inland content access to daily updates Auto Guidance+ technology and more.

Includes GMR 18 HD3 Radome - To help avoid weather and traffic on the water the compact 4 kW GMR 18 HD+ dome radar is bundled with this GPSMAP chartplotter/sonar package.

Power-Pole Shallow Water Anchor - By networking selected Garmin chartplotters with a Force trolling motor and a compatible Power-Pole shallow water anchoring system access advanced boat control features from the plotter including smart anchor auto-deployment smart anchor jog auto stow anchor drag detection and auto guidance end-of-route anchoring.

Sail and Navigate with Ease

Garmin SailAssist Sailing Features - View laylines race start line guidance enhanced wind rose heading and course-over-ground lines true wind data fields and tide/current/time slider wind angle set and drift wind speed and more.

Optional Premium Navigation Features - These optional charts offer the best of Garmin and Navionics data Auto Guidance technology and other premium navigation features.

Sailing Polars - Use the polar table to see key data including how fast the boat should go at a certain wind angle and speed - know whether there is a need to adjust sail trim.

Garmin Marine Network - If there are multiple compatible Garmin devices on the boat share information - such as maps user data radar and IP camera video - among them.

NMEA 2000 and NMEA 0183 Networks - Connect to compatible autopilots digital switching weather Fusion-Link audio system media VHF AIS and more from one screen.

ActiveCaptain App - Built-in Wi-Fi connectivity pairs with the free all-in-one mobile app for access to the OneChart feature smart notifications software updates Garmin Helm digital switching Garmin Quickdraw Community.

Integrated ANT Technology - Connect with devices such as quatix marine watches gWind Wireless 2 transducers transducers GNX Wind marine instruments and wireless remote controls.

Engine Connectivity - Connect the chartplotter to different kinds of engines including selected Yamaha engines.

OneHelm Feature - This feature brings together all the operations and capabilities of selected third-party devices such as EmpirBus digital switching on one screen.

Send InReach Device Messages - Pair an inReach satellite communicator to the chartplotter and type custom messages using the MFD’s on-screen keyboard. Access the contact list or enter an email inReach address or phone number. Group messages by conversation for a texting-like experience.

In The Box

• GPSMAP 1223xsv chartplotter
• GMR 18 HD3 radome
• Radar Mounting hardware kit
• Radar Power cable (15 metres)
• Radar Network cable (15 metres)
• Installation instructions
• microSD card preinstalled
• GPSMAP Power cable
• NMEA 2000 T-connector
• NMEA 2000 drop cable (2 metres)
• 8-pin transducer to 12-pin sounder adapter cable
• Bail mount kit with knobs
• Flush mount kit with gasket
• Protective cover
• Trim piece snap covers
• Documentation
• Mounting templates
