Description
xTechnische Basisdaten
| Hersteller: FAG |
| Synonym: 0390600630030 6330M/C3VL0241 |
| C3: Internal clearance greater than Normal. The extra internal clearance allows expansion due to high speeds or temperatures. |
| J20AA: External surfaces of the outer ring coated with aluminium oxide. The coating is sealed with a resin to protect against the conductive effects of water and moisture. This basic coating can withstand voltages up to 3.000 V DC. |
| M: Machined Brass Cage, Ball Centered. |
Erweiterte technische Daten
| Äußeres Breitenmaße: mm 320,00 |
| Begrenzungsdrehzahl (n G) "3600.0000" |
| Äußeres Breitenmaße: mm 65,00 |
| Äußeres Breitenmaße: mm 65,00 |
| C3 Internal Clearance Larger Than Normal |
| ECLASS number 23-05-08-01 |
| ECLASS2 number 23-05-08-01 |
| Einzelgewicht in (kg): 25.3 |
| Innenmaße: mm 150,00 |
| Interne Radialluft C3 Innenluft (größer als Cn) |
| J20AA Coating Which Consists Of Oxide Ceramic, It Is Applied By Plasma Spraying And Then Sealed With Synthetic Resin. Speciality Humid Environments |
| M Solid Brass Cage, Ball-Guided |
| Präzision Breakdown Voltage 1000v |
| Radial Dynamic Load Rating Cr (N) 300000 |
| Radial Static Load Rating C0r (N) 290000 |
| Referenzdrehzahl (n ϑr) "3000.0000" |
| Spezialbehandlung Keine Spezialbehandlung |
| Generators (wind power) |
| Gewicht 22,75 kg |
| Industrial electric motors |
| Interchangeable with standard bearings (same dimensions and performance) |
| Outer ring coated with aluminium oxide |
| Power transmissions |
| Prevent downtime and lost production |
| Protection against electric current passage |
| Wheel sets and traction motors (rail vehicles) |
